Server connection details
Server Integration
| EU platform | tracker.navixy.com (52.57.1.136) | |
| US platform | tracker.us.navixy.com (13.52.37.2) | |
| Server port | 47764 | |
| Integrated on | 04/08/2014 | |
| Revised on | 19/02/2015 |
General information
| Purpose | Vehicle | |
| Installation | Professional |
Housing
| Weight | 71 g (2.5 oz.) | |
| Size | 80x49x26 mm (3.15x1.93x1.02 in) |
GNSS Location
| Internal antenna (GNSS) | ||
| External antenna (GNSS) | Optional | |
| GPS | ||
| Assisted GPS | ||
| Chipset | u-blox |
Connectivity
| Cellular network type | GSM Quad Band, CDMA2000 800/1900 | |
| Internal antenna (Connection) | ||
| Cellular network generation | 3G |
Interfaces
| Number of RS232 interfaces | 1 | |
| RS232 interface | ||
| Number of outputs | 3 | |
| Number of inputs (all types) | 5 | |
| ACC/Ignition input | ||
| Discrete inputs | Feature already supported | |
| Analog inputs | Feature already supported | |
| Outputs | Feature already supported |
Hardware features
| Battery capacity | 250, number-mah-0 mAh | |
| Built-in battery | ||
| Emergency button | ||
| Accelerometer |
Hardware extras
| Driver ID reading | Feature already supported |
Tracking features
| Location by Cell ID | Feature already supported | |
| Smart power consumption | Feature already supported | |
| Odometer | Feature already supported | |
| ECO driving | Feature already supported |
Events monitoring
| Input change | Feature already supported | |
| External power cut off | Feature already supported | |
| Towing | Feature already supported |
Self monitoring
| Network signal level | Feature already supported | |
| GNSS signal level | Feature already supported | |
| GNSS satellites fixed | Feature already supported | |
| External power source voltage | Feature already supported | |
| Internal battery level | Feature already supported |
CAN/OBDII reading
| CAN/OBDII parameters | Fuel level, fuel consumption, engine RPM, throttle position, speed, engine load, coolant temperature, DTC error codes and other, Yes | Feature already supported |
| DTC codes reading | Feature already supported |
Remote management
| Server connection setup over SMS | Feature already supported | |
| Remote device configuration | Yes (over GPRS) | Feature already supported |
| Remote outputs control | Yes (over GPRS) | |
| Forced LBS location update over GPRS | Feature already supported | |
| Forced GNSS location update over SMS | Feature already supported |
